Flexible Waterproof 5V, IP65 RGB Addressable LED Strip - 1M (5050) SMD 60 LEDs/m
The WS2812B Individually Addressable RGB LED Strip is a flexible 5V strip with 60 LEDs per meter and 60 control ICs per meter over a 1-meter length. Every LED can be controlled on its own, so you can create custom colors and dynamic lighting effects. It has an IP65 silicone layer waterproof coating, a 120° viewing angle, and a color rendering index above RA90. The 10mm FPCB uses a simple 3-pin interface (+5V, Data, GND). It works with controllers such as Arduino, Raspberry Pi, and ESP32 WLED controllers, which makes it a good fit for DIY, decorative, and architectural lighting projects.
شريط إضاءة LED من نوع WS2812B قابل للتحكم الفردي بكل LED بألوان RGB، وهو شريط مرن يعمل على جهد 5 فولت ويحتوي على 60 LED لكل متر و60 شريحة تحكم IC لكل متر بطول 1 متر. يمكن التحكم في كل LED بشكل منفصل، وهذا يسمح بإنشاء ألوان مخصصة وتأثيرات إضاءة ديناميكية. الشريط مزود بطبقة سيليكون مقاومة للماء بمعيار IP65، وزاوية رؤية 120°، ومؤشر تجسيد ألوان أعلى من RA90. عرض اللوحة المرنة 10 ملم، ويتصل عبر 3 أطراف بسيطة (+5V، البيانات، GND). يعمل مع وحدات تحكم مثل Arduino وRaspberry Pi وESP32 WLED، لذلك يناسب مشاريع الإضاءة الخاصة والديكور والإضاءة المعمارية.
The WS2812B Individually Addressable RGB LED Strip is a flexible lighting strip that runs on DC 5V. It has 60 LEDs per meter across a 1-meter (3.2 ft) length, and each LED comes with its own control IC, giving 60 ICs per meter. Because every LED is addressed separately, you can set the color and brightness of each one and build animations, color chases, and custom lighting effects.
The strip is protected by an IP65 silicone layer waterproof coating. Its 10mm (0.39 in) flexible PCB delivers a 120° viewing angle and a high color rendering index (RA>90). The color order is GRB, and it connects through a 3-pin interface: +5V (+V), DI (Data Input) / DO (Data Output), and GND (-V). Strips can be joined in series by following the data direction. Maximum power consumption is 11W per meter.
The strip works with a wide range of controllers, including Arduino, Raspberry Pi, ESP32 WLED WiFi controllers, and Bluetooth, WiFi, and music controllers. It is UL certified for North America, confirming full compliance with U.S. and Canadian electrical safety standards.
Important precautions:
- Use only a 5V power supply. A higher voltage will burn the LED strip.
- LEDs at the far end may look dimmer because of voltage drop. To fix this, add voltage supplementation, lower the brightness, make sure the power supply is sufficient, and avoid full white lighting.
- Keep the bending radius above 30mm (1.2 in), and do not bend, fold, or crease the strip horizontally.
- Do not run the strip while it is rolled up, because heat does not dissipate well and the strip can be damaged.
- Take anti-static measures, and press on the PCB rather than the LED surface during installation.
Specifications
| Parameter | Value |
|---|---|
| LED Type | WS2812B Individually Addressable RGB |
| Input Voltage | DC 5V |
| LED Quantity | 60 LEDs/m |
| IC Chip Quantity | 60 IC/m |
| Total Length | 1m (3.2 ft) |
| Maximum Power | 11W/m |
| FPCB Width | 10mm (0.39 in) |
| View Angle | 120° |
| Color Rendering Index | RA > 90 |
| Waterproof Level | IP65 (Silicone layer waterproof) |
| Color Order | GRB |
| Pin Connection | +5V (+V), DI Data Input / DO Data Output, GND (-V) |
| Operating Temperature | -20°C to +45°C |
| Storage Temperature | -20°C to +40°C |
| Minimum Bending Radius | > 30mm (1.2 in) |
| Certification | UL Certified (North America) |
Applications
- Staircase lighting
- Wine cabinet lighting
- Ceiling lighting
- Hallway lighting
- Cabinet lighting
- DIY electronics projects with Arduino, Raspberry Pi, and ESP32
- Smart home lighting with WiFi, Bluetooth, and voice-controlled systems (Alexa / Google Home)
- Music-reactive lighting with music controllers
