UNO Shield Ethernet Shield W5500 R3 Development board FOR arduino
The UNO Ethernet Shield W5500 R3 enables Arduino boards to connect to wired networks. Featuring a W5500 controller, it supports TCP/IP communication, HTTP, and Ethernet-based projects, making it ideal for IoT, networking, and smart home applications.
درع UNO Ethernet Shield W5500 R3 يتيح لألواح Arduino الاتصال بالشبكات السلكية. مزود بوحدة تحكم W5500، يدعم TCP/IP، HTTP، والمشاريع المعتمدة على الإيثرنت، مما يجعله مثالياً لتطبيقات إنترنت الأشياء (IoT)، الشبكات، والمنازل الذكية.
The UNO Ethernet Shield W5500 R3 is designed to add Ethernet connectivity to Arduino boards (UNO, Mega, etc.). Powered by the W5500 chip, it provides reliable TCP/IP communication, SPI interface support, and an easy integration path for Ethernet-based IoT and automation projects. Its standard pinout allows stacking directly on Arduino boards without additional wiring.
Specifications:
Model: UNO Ethernet Shield W5500 R3
Network Chip: W5500 Ethernet controller
Interface: SPI
Supported Protocols: TCP, UDP, IPv4, DHCP, HTTP, FTP
Operating Voltage: 5V DC
LEDs: Power, Link, and Activity indicators
Mounting: Stackable shield for Arduino UNO, Mega, and compatible boards
Connector: Standard RJ45 Ethernet port
