ESP32-C6-WROOM-1-N16 Module Espressif System WIFI and BLUETOOTH
The ESP32-C6-WROOM-1-N16 module by Espressif Systems is a high-performance multiprotocol wireless module built around the ESP32-C6 SoC. It supports Wi-Fi 6 (802.11ax), Bluetooth LE, and IEEE 802.15.4 for Zigbee and Thread applications. Featuring a 32-bit RISC-V processor up to 160MHz, onboard PCB antenna, 4MB flash, and rich peripherals, it delivers secure, reliable connectivity for smart homes, industrial automation, healthcare, and IoT devices.
وحدة ESP32-C6-WROOM-1-N16 من شركة Espressif Systems هي وحدة لاسلكية متعددة البروتوكولات عالية الأداء، مبنية على الشريحة ESP32-C6. تدعم الوحدة Wi-Fi 6 (802.11ax) وBluetooth منخفض الطاقة (BLE) ومعيار IEEE 802.15.4 لتطبيقات Zigbee وThread.
تتميز بمعالج RISC-V 32-بت بسرعة تصل إلى 160 ميجاهرتز، وهوائي PCB مدمج، وذاكرة فلاش بسعة 4 ميجابايت، ومجموعة غنية من الواجهات الطرفية، ما يوفّر اتصالًا آمنًا وموثوقًا لتطبيقات المنازل الذكية والأتمتة الصناعية والرعاية الصحية وأجهزة إنترنت الأشياء.
The ESP32-C6-WROOM-1-N16 is a powerful multiprotocol wireless communication module designed for advanced IoT and embedded applications. Developed by Espressif Systems, it is based on the ESP32-C6 series SoC featuring a 32-bit RISC-V single-core processor running up to 160 MHz.
This module supports Wi-Fi 6 (IEEE 802.11ax), Bluetooth® LE, and IEEE 802.15.4, enabling seamless integration of Zigbee and Thread protocols. It combines strong RF performance with low power consumption and enhanced link robustness, making it ideal for next-generation smart devices.
The module integrates CPU, on-chip memory, 4MB SPI flash, crystal oscillator, RF components, and an onboard PCB antenna. It also offers 23 GPIOs and rich peripheral interfaces such as SPI, parallel I/O, and JTAG debugging support through the SoC event task matrix.
Operating within a 3V to 3.6V voltage range, the ESP32-C6-WROOM-1-N16 module is optimized for smart home systems, industrial automation, healthcare equipment, and consumer electronics.
Specifications
🔸 Processor & Memory
SoC: ESP32-C6
CPU: 32-bit RISC-V single-core up to 160 MHz
ROM: 320KB
SRAM: 512KB
LP SRAM: 16KB
Flash: 4MB SPI Flash
Crystal Oscillator: 40MHz
🔸 Wireless Connectivity
Wi-Fi (IEEE 802.11ax)
2.4GHz band (2412MHz – 2484MHz)
Data rate up to 150 Mbps
Beamformee support
Channel Quality Indication (CQI)
Dual Carrier Modulation (DCM)
Spatial reuse
Target Wake Time (TWT)
Fully compatible with 802.11b/g/n
Wi-Fi Multimedia (WMM)
Immediate Block ACK
Fragmentation & Defragmentation
Transmit Opportunity (TXOP)
Automatic Beacon Monitoring (Hardware TSF)
Bluetooth® LE
Multiple advertisement sets
Advertising extensions
High power mode (shared PA with Wi-Fi)
IEEE 802.15.4
Supports Zigbee
Supports Thread
🔸 Interfaces & Peripherals
23 GPIOs
SPI
Parallel I/O interface
JTAG debugging
SoC event task matrix controller
🔸 Antenna
On-board PCB antenna
🔸 Electrical
Operating Voltage: 3V – 3.6V
Applications
Smart home devices
Industrial automation systems
Healthcare monitoring equipment
Consumer electronics
Smart lighting systems
IoT gateways
Zigbee / Thread devices
Wireless sensors and controllers
