Non-contact LCD Digital Tachometer Test Meter Air Flow Speedometer Tester
The HYELEC MS6208B Digital Tachometer is a professional non-contact speed measuring instrument designed for industrial and agricultural applications. It accurately measures rotational speed from 50RPM to 9999RPM using reflected light technology. Featuring a backlit LCD display, data logging, MAX/MIN/AVG functions, and multiple speed units, the device provides reliable and convenient performance for machinery maintenance, airflow measurement, and motor testing.
جهاز HYELEC MS6208B هو مقياس سرعة رقمي احترافي يعمل بدون تلامس، مصمم للاستخدامات الصناعية والزراعية. يقيس سرعة الدوران بدقة من 50 إلى 9999 دورة في الدقيقة باستخدام تقنية انعكاس الضوء. يتميز بشاشة LCD بإضاءة خلفية وتسجيل للبيانات ووظائف MAX/MIN/AVG ودعم عدة وحدات قياس، مما يجعله مناسبًا لفحص المحركات وقياس سرعة الدوران وتطبيقات الصيانة المختلفة.
The HYELEC MS6208B Digital Tachometer is a high-precision non-contact measuring instrument designed for accurately measuring rotational speed and airflow-related motion in industrial, agricultural, and maintenance environments.
The device uses reflected light sampling technology combined with a high-speed integrated processing chip to calculate accurate RPM readings without requiring physical contact with moving components. This non-contact design improves safety and measurement convenience while reducing wear on both the device and the tested equipment.
The tachometer supports a wide measurement range from 50RPM to 9999RPM and provides stable, high-reliability performance. Its backlit LCD screen ensures clear visibility in low-light environments, while additional functions such as MAX/MIN/AVG measurement, data logging, and data hold enhance usability during professional testing applications.
The MS6208B also supports multiple speed and airflow units including m/min, m/sec, ft/min, ft/sec, and in/min, making it suitable for a wide range of measurement tasks.
Powered by four AAA batteries, the device offers portability and automatic power-saving functionality with auto shut-off after 30 seconds of inactivity.
Specifications
- Brand: HYELEC
- Model: MS6208B
- Product Type: Non-Contact Digital Tachometer
- Measurement Method: Reflected light non-contact measurement
- Measurement Range: 50RPM – 9999RPM
- Measurement Accuracy: ±(0.03% + 2 digits)
- Measuring Distance: 50mm – 250mm
- Display Type: Backlit LCD
- Auto Power Off: 30 seconds
- Functions:
- MAX / MIN / AVG measurement
- Data Hold
- Data Logging
- Backlight
- Low Battery Indication
- Data Logging Capacity: 100 groups
- Supported Units:
- m/min
- m/sec
- ft/min
- ft/sec
- in/min
- Power Supply: 4 × 1.5V AAA batteries (not included)
- Material: ABS plastic
- Product Dimensions: 193 × 60 × 29 mm
- Package Dimensions: 200 × 120 × 75 mm
- Product Weight: Approximately 0.352kg
- Certification: CE, RoHS
Applications
- Motor speed measurement
- Industrial machinery testing
- Agricultural equipment maintenance
- Fan and airflow speed monitoring
- Mechanical rotation analysis
- Workshop maintenance operations
- Quality control inspections
- Production line diagnostics
- HVAC system testing
- Engineering and laboratory applications
