Energy Meter TS-838
Out Of Stock
The TS-838 Energy Meter is a digital power monitoring device designed to measure and display key electrical parameters for household and commercial appliances. Featuring a clear LCD screen, it provides real-time readings of voltage, current, power factor, operating time, and energy consumption. Users can set electricity tariffs to automatically calculate power costs and configure overload alarms for enhanced equipment protection. The meter operates on AC 230V, 50Hz systems and supports loads up to 16A. With built-in clock functions and backup batteries, the TS-838 offers a convenient and reliable solution for monitoring energy usage and improving electrical efficiency.
يُعد مقياس الطاقة TS-838 جهازًا رقميًا متطورًا لمراقبة استهلاك الطاقة الكهربائية في الأجهزة المنزلية والتجارية. يتميز بشاشة LCD واضحة تعرض بيانات فورية تشمل الجهد الكهربائي، التيار، معامل القدرة، زمن التشغيل، واستهلاك الطاقة. يتيح للمستخدم ضبط سعر الكيلوواط ساعة ليقوم الجهاز بحساب تكلفة الكهرباء تلقائيًا، كما يوفر خاصية ضبط إنذار زيادة الحمل لحماية الأجهزة الكهربائية. يعمل الجهاز على جهد 230 فولت AC بتردد 50 هرتز ويدعم تيارًا يصل إلى 16 أمبير. بفضل وظيفة الساعة والبطاريات الاحتياطية، يوفر TS-838 وسيلة عملية وموثوقة لإدارة ومراقبة استهلاك الطاقة بكفاءة.
The TS-838 Energy Meter is a multifunctional digital electricity monitoring device designed to help users measure, analyze, and manage energy consumption. Equipped with a large LCD display, the meter provides accurate real-time information about electrical performance, including voltage, current, power factor, operating time, and accumulated energy usage.
The device includes an integrated electricity cost calculation function that allows users to enter the local electricity tariff rate. Based on the measured energy consumption, the meter automatically calculates the total electricity cost, making it ideal for monitoring household appliances, office equipment, and industrial devices.
For added safety, the TS-838 features an adjustable overload alarm. Users can set a maximum power threshold, and the meter will trigger an alarm whenever the connected load exceeds the preset value. The built-in clock supports both 12-hour and 24-hour formats and is maintained by two replaceable 1.5V button batteries.
Designed for ease of use and long-term reliability, the TS-838 is an effective tool for reducing energy waste, tracking appliance performance, and controlling electricity expenses.
Specifications
Model: TS-838
Display Type: Digital LCD Display
Operating Voltage: AC 230V, 50Hz
Voltage Range: 190V – 276V AC
Maximum Operating Current: 16A
Minimum Detectable Current: 0.005A
Power Supply Backup: 2 × 1.5V Replaceable Button Batteries
Time Format: 12-Hour / 24-Hour
Functions:
- Voltage Measurement
- Current Measurement
- Power Factor Display
- Operating Time Display
- Energy Consumption Monitoring
- Electricity Cost Calculation
- Overload Alarm Setting
- Clock Function
Housing Material: ABS Plastic
Applications
- Household appliance energy monitoring
- Office equipment power consumption tracking
- Air conditioners and refrigeration systems
- Washing machines and dryers
- Water heaters and electric heaters
- Computer and server power monitoring
- Industrial and workshop equipment
- Energy-saving and efficiency projects
- Rental property electricity usage monitoring
- Educational and laboratory applications
