Flexible Solar Panel 6V 1W Thin-film
Flexible Thin-Film Solar Panel 6V 1W is an ultra-lightweight and bendable solar panel designed for portable and space-constrained renewable energy applications. Built using flexible amorphous silicon thin-film solar cell technology, it can conform to curved surfaces with up to 30° bending capability. The panel is protected by durable ETFE and EVA layers, providing excellent light transmission and weather resistance. Its waterproof, lightweight, and chainable design makes it ideal for battery charging, outdoor electronics, IoT devices, educational projects, and portable solar-powered systems where traditional rigid panels are not practical.
لوح شمسي مرن رقيق 6 فولت 1 واط هو لوح طاقة شمسية خفيف الوزن وقابل للانحناء، مصمم للتطبيقات المحمولة والمشاريع التي تتطلب تركيباً على أسطح منحنية. يعتمد على تقنية الخلايا الشمسية الرقيقة من السيليكون غير المتبلور المرن، مما يسمح بثنيه حتى زاوية 30 درجة دون التأثير على الأداء. يتميز بطبقات حماية من ETFE و EVA عالية الشفافية والمتانة لتوفير مقاومة للعوامل الجوية وتحسين كفاءة امتصاص الضوء. يعد مثالياً لشحن البطاريات وتشغيل الأجهزة الإلكترونية الخارجية ومشاريع إنترنت الأشياء والطاقة الشمسية المحمولة.
The Flexible Thin-Film Solar Panel 6V 1W is an innovative solar energy solution designed for applications where traditional rigid solar panels cannot be easily installed. Constructed using advanced amorphous silicon thin-film solar technology, the panel provides flexibility, lightweight construction, and reliable solar energy generation.
The ultra-thin design allows installation on curved surfaces with bending angles up to 30 degrees, making it suitable for portable devices, outdoor equipment, wearable electronics, and custom renewable energy projects. The panel is laminated with durable ETFE (Ethylene Tetrafluoroethylene) film and fast-curing EVA (Ethylene Vinyl Acetate) layers that enhance durability, weather resistance, and light transmission.
Its chainable design allows multiple panels to be connected together to increase voltage or power output according to project requirements. The lightweight construction makes it especially useful in portable and weight-sensitive applications.
This flexible solar panel is an excellent choice for makers, engineers, students, and renewable energy enthusiasts looking for a compact and adaptable power generation solution.
Specifications
| Parameter | Specification |
|---|---|
| Product Name | Flexible Thin-Film Solar Panel |
| Solar Cell Technology | Flexible Amorphous Silicon Thin Film |
| Rated Voltage | 6V DC |
| Rated Power | 1W |
| Conversion Efficiency | Approximately 10% |
| Cell Structure | Three-Junction Thin-Film Cells |
| Panel Type | Flexible |
| Waterproof | Yes |
| Chainable | Yes |
| Maximum Bending Angle | 30° |
| Main Material | ETFE + EVA Laminated Structure |
| Dimensions (Active Area) | 186 × 78 × 0.5 mm |
| Dimensions (Including Edge) | 208 × 78 × 0.5 mm |
| Weight | 29g ± 2g |
Applications
- Battery charging systems
- Portable solar chargers
- Outdoor electronic devices
- IoT and remote sensor systems
- Educational renewable energy projects
- DIY solar-powered projects
- Wearable electronics
- Smart agriculture monitoring systems
- Camping and outdoor equipment
- Low-power embedded systems
- Mobile energy harvesting applications
- Custom curved-surface installations
