Arduino Sensor Shield
Arduino Sensor Shield V4.0 Expansion Board for Arduino UNO Compatible Boards
The Arduino Sensor Shield V4.0 is a convenient expansion board designed to simplify connections between an Arduino and external modules. It provides clearly labeled digital, analog, power, and communication ports, allowing sensors, servos, relays, buttons, and other modules to be connected quickly without complex wiring. Featuring a plug-and-play design, the shield uses standard 2.54mm connectors with dedicated VCC, GND, and signal pins for each interface. Compatible with Arduino UNO and similar microcontroller boards, it is an excellent solution for prototyping, educational projects, robotics, and sensor-based applications while maintaining organized and reliable connections.
يُعد Arduino Sensor Shield V4.0 لوحة توسعة عملية مصممة لتسهيل توصيل الحساسات والوحدات الإلكترونية المختلفة مع لوحات الأردوينو. يوفر منافذ رقمية وتناظرية ومنافذ طاقة واتصالات مرتبة بوضوح، مما يسمح بتوصيل الحساسات، والمحركات المؤازرة، والريليه، والأزرار، وغيرها بسهولة دون الحاجة إلى توصيلات معقدة. يعتمد على تصميم Plug & Play باستخدام موصلات قياسية 2.54 مم تحتوي على أطراف الإشارة والطاقة والأرضي. يتوافق مع لوحات Arduino UNO واللوحات المتوافقة معها، مما يجعله مناسبًا للتعليم، والروبوتات، ومشاريع النماذج الأولية، والتطبيقات الإلكترونية المختلفة.
The Arduino Sensor Shield V4.0 is an expansion board developed to simplify interfacing between Arduino boards and a wide variety of electronic modules. By providing dedicated connection headers for digital and analog devices, it eliminates the need for complex breadboard wiring and makes project assembly faster and more reliable.
The shield includes clearly marked VCC, GND, and Signal pins for every I/O connection, enabling direct connection of sensors, servos, relays, switches, and communication modules. It also provides dedicated communication interfaces supporting I2C and UART, making integration of advanced peripherals straightforward.
Designed with a standard Arduino form factor, the Sensor Shield fits directly onto compatible Arduino boards, creating a clean and professional-looking setup suitable for educational use, robotics projects, automation systems, and rapid prototyping.
Specifications
| Parameter | Value |
|---|---|
| Model | Sensor Shield V4.0 |
| Compatibility | Arduino UNO and Compatible Boards |
| Digital I/O Ports | 13 Ports |
| Analog Input Ports | 6 Ports |
| Communication Interface | I2C / UART Selectable |
| Connector Type | 2.54mm Headers |
| Power Connections | VCC, GND, Signal for Each Port |
| Dimensions | 67.9 × 56.8 mm |
| Weight | 25 g |
Applications
- Arduino prototyping projects
- Robotics and automation systems
- Educational electronics training
- Sensor integration projects
- Servo motor control systems
- Relay control applications
- Smart home development
- IoT and embedded systems
- STEM learning projects
- Rapid hardware development and testing
