MICRO USB to DIP Adapter 5pin Female Connector B Type PCB Converter
The Micro USB to DIP Adapter Module is a compact breakout board designed to convert a standard Micro USB Type-B female connector into easy-to-use 2.54mm DIP pins for breadboards and prototype circuits. It exposes all 5 USB pins (VBUS, D+, D-, ID, and GND), allowing convenient access for power and data connections. This adapter eliminates the difficulty of soldering directly to small USB connectors, making it ideal for DIY electronics, USB-powered projects, microcontroller development, testing mobile chargers, and rapid prototyping. Its simple design and standard pin spacing ensure easy integration into a wide variety of electronic applications.
تُعد وحدة محول Micro USB إلى DIP لوحة تحويل مدمجة مصممة لتحويل موصل Micro USB Type-B الأنثى إلى أطراف DIP بمسافة 2.54 مم مناسبة للوحات التجارب والدوائر الإلكترونية. توفر اللوحة الوصول إلى جميع أطراف USB الخمسة (VBUS وD+ وD- وID وGND) لتوصيلات الطاقة والبيانات بسهولة. تساعد هذه الوحدة على تجنب صعوبة لحام موصلات USB الصغيرة، مما يجعلها مثالية لمشاريع الإلكترونيات التعليمية، ومشاريع التغذية عبر USB، وتطوير المتحكمات الدقيقة، واختبار الشواحن، والنماذج الأولية السريعة. كما يضمن تصميمها البسيط سهولة دمجها في مختلف التطبيقات الإلكترونية.
The Micro USB to DIP Adapter Module is a practical interface board that simplifies the integration of a Micro USB Type-B female connector into electronic circuits and development projects. The module breaks out all five USB connections to standard 2.54mm pitch header pins, making it compatible with breadboards, prototype boards, and custom PCB designs.
This adapter provides access to VBUS, D+, D-, ID, and GND, enabling both USB power and data applications. It is particularly useful for engineers, students, and hobbyists who need USB connectivity without the challenges of soldering directly to miniature USB connectors.
The board is commonly used for USB-powered devices, microcontroller projects, charger testing, and prototyping applications. Its compact size and standard pin spacing allow quick integration into a wide range of electronic designs.
Specifications
| Parameter | Specification |
|---|---|
| Product Type | Micro USB to DIP Adapter |
| USB Connector Type | Micro USB Type-B Female |
| Number of USB Pins | 5 Pins |
| Broken-Out Signals | VBUS, D+, D-, ID, GND |
| Header Pitch | 2.54 mm |
| Mounting Type | Through-Hole DIP |
| Board Type | USB Breakout Board |
| Compatibility | Breadboards, Prototype Boards, Custom PCBs |
| Function | USB Power and Data Interface |
| Connector Gender | Female |
Applications
- USB power supply projects
- Arduino and microcontroller development
- Breadboard prototyping
- USB charger testing
- DIY electronics projects
- Embedded system development
- USB communication circuits
- Educational electronics experiments
- Custom PCB testing and debugging
- Portable device power connections
