7SEGMENT LED DISPLAY 0.8 inch Common Anode

5.0(1 review)
SKU: ME-3684
JD1.25

The 0.8-inch 7-Segment LED Display (Common Anode) is a bright and reliable numeric display module designed for electronic projects, industrial equipment, measurement devices, and digital counters. Its large 0.8-inch digit height provides excellent visibility from a distance, making it suitable for both indoor and outdoor applications. The common anode configuration allows easy interfacing with microcontrollers, driver ICs, and digital circuits. Featuring low power consumption, fast response time, and high brightness, this LED display is ideal for clocks, timers, voltage meters, frequency counters, and other systems that require clear and accurate numerical indication.

شاشة LED سباعية القطاعات مقاس 0.8 بوصة (Common Anode) هي وحدة عرض رقمية عالية السطوع والاعتمادية، مصممة للاستخدام في المشاريع الإلكترونية والأجهزة الصناعية وأنظمة القياس والعدادات الرقمية. يوفر ارتفاع الرقم 0.8 بوصة رؤية واضحة من مسافات بعيدة، مما يجعلها مناسبة للتطبيقات الداخلية والخارجية. يتيح تصميم الأنود المشترك (Common Anode) سهولة التوصيل مع المتحكمات الدقيقة ودوائر القيادة الإلكترونية. تتميز باستهلاك منخفض للطاقة، واستجابة سريعة، وإضاءة قوية، مما يجعلها مثالية للساعات الرقمية، والمؤقتات، وأجهزة قياس الجهد، وعدادات التردد، وغيرها من التطبيقات التي تتطلب عرضًا رقميًا واضحًا ودقيقًا.

7-Segments

The 0.8-inch 7-Segment LED Display Common Anode is a high-visibility numeric display component used for displaying digits in electronic circuits and embedded systems. Each digit consists of seven individually controlled LED segments that can be illuminated in different combinations to form numbers from 0 to 9 and certain alphabetic characters.

With its large 0.8-inch digit size, the display offers excellent readability, making it suitable for applications where viewing distance is important. The common anode configuration means all LED segment anodes are internally connected together, while individual cathodes control each segment. This design allows straightforward interfacing with microcontrollers, shift registers, and display driver ICs.

The display provides high brightness, low power consumption, long operational life, and fast switching speed, making it a dependable solution for digital indication systems in consumer, educational, and industrial electronics.

Specifications

ParameterSpecification
Product Type7-Segment LED Display
Digit Height0.8 inch (20.3 mm)
Display ColorRed (typical)
ConfigurationCommon Anode
Number of Segments7 Segments + Decimal Point
Viewing AngleWide Viewing Angle
Operating VoltageTypically 1.8V – 2.2V per segment
Forward CurrentTypically 10–20 mA per segment
Response TimeFast LED Response
Mounting TypeThrough-Hole PCB Mount
Power ConsumptionLow Power
VisibilityHigh Brightness
Operating LifeLong Service Life

Applications

  • Digital clocks and timers
  • Electronic counters
  • Frequency measurement instruments
  • Voltage and current meters
  • Temperature display systems
  • Industrial control panels
  • Educational electronics projects
  • Microcontroller-based systems
  • Scoreboards and numeric indicators
  • Test and measurement equipment
  • Process monitoring displays
  • Embedded electronic devices
