43A H-Bridge Drive BTS7960
The BTS7960B 43A H-Bridge Motor Driver is a high-power, dual BTS7960 half-bridge module designed for demanding DC motor control applications. Supporting a wide supply range of 5.5V to 27V and delivering up to 43A of continuous current, it accepts 3.3V–5V logic inputs for easy integration with microcontrollers like Arduino. The module features built-in protection against overtemperature, overvoltage, undervoltage, overcurrent, and short circuits, along with PWM control up to 25 kHz and active freewheeling. Its compact design, current-sense diagnosis, and adjustable slew rate make it ideal for robotics, electric vehicles, and industrial motor projects.
وحدة تشغيل المحركات BTS7960B بجسر كامل وتيار 43 أمبير هي موديول قوي مزدوج يعتمد على شريحة BTS7960 مصمم للتحكم في محركات التيار المستمر عالية الاستهلاك. يدعم جهد تغذية واسع من 5.5 فولت إلى 27 فولت ويوفر تياراً مستمراً يصل إلى 43 أمبير، مع مداخل منطقية 3.3–5 فولت تتوافق مع المتحكمات مثل Arduino. يحتوي على حماية متكاملة من ارتفاع الحرارة، الجهد الزائد، الجهد المنخفض، التيار الزائد، والدائرة القصيرة، بالإضافة إلى دعم PWM حتى 25 كيلوهرتز. تصميمه المدمج وقياس التيار المدمج يجعله مثالياً للروبوتات والمركبات الكهربائية والمشاريع الصناعية.
The Double BTS7960 43A H-Bridge High-Power Motor Driver Module is a fully integrated high-current H-bridge solution engineered for heavy-duty motor drive applications. Built around two BTS7960 high-current half-bridge chips from the NovalithIC™ family, this module provides a powerful, reliable, and easy-to-use platform for controlling DC motors with precision.
Each BTS7960 package integrates a p-channel high-side MOSFET, an n-channel low-side MOSFET, and a dedicated driver IC in a single housing. The use of a p-channel high-side switch eliminates the requirement for a charge pump, which significantly reduces electromagnetic interference (EMI) and simplifies the overall circuit design.
The integrated driver IC simplifies microcontroller interfacing by accepting logic-level inputs, while offering advanced features such as current-sense diagnosis, adjustable slew rate, dead-time generation, and comprehensive protection against overtemperature, overvoltage, undervoltage, overcurrent, and short circuits. These built-in safeguards protect both the driver and the connected motor, making the module suitable for long-duty-cycle operation.
With a compact footprint, low on-state resistance, and support for PWM frequencies up to 25 kHz with active freewheeling, this module delivers efficient power handling with minimal heat generation. It works seamlessly with microcontrollers like Arduino, requiring only jumper wires and a suitable battery or power supply to operate. This makes it a cost-effective and robust solution for robotics, electric vehicles, automation systems, and other high-current motor control projects.
Specifications
- Input Voltage: 6 – 27 V
- Supply Voltage Range: 5.5V to 27V
- Maximum Current: 43 A
- Logic Input Level: 3.3 – 5 V
- Operating PWM Frequency: Up to 25 kHz
- Path Resistance (Typical): 16 mΩ @ 25 °C
- Quiescent Current (Typical): 7 µA @ 25 °C
- Current Limitation Level (Typical): 43 A
- Dimensions: 50 x 50 x 43 mm
- Weight: 67 g
- Onboard 5V power indicator LED
Applications
- Robotics and Autonomous Vehicles – driving high-power DC motors for wheels, arms, and actuators
- Electric Vehicles (EVs) – including e-bikes, e-scooters, and small electric carts
- Industrial Automation – conveyor belts, pumps, and actuator systems
- CNC Machines and 3D Printers – for precise high-torque motor control
- Smart Home Systems – automated gates, blinds, and linear actuators
- RC Models and Hobby Projects – large-scale remote-controlled cars, boats, and tanks
- Agricultural and Marine Equipment – bilge pumps, winches, and trolling motors
- DIY Power Tools – custom drills, saws, and high-torque mechanisms
- Solar Tracking Systems – motorized panel positioning
- Arduino and Raspberry Pi Projects – high-current motor control with microcontroller compatibility
