SINGLE SIDE PROTOTYPE PCB 10X22 CM
The Single-Sided Prototype PCB 10×22 cm is a high-quality universal perforated circuit board designed for building and testing electronic circuits without the need for custom PCB fabrication. With 2,730 plated holes at standard 2.54mm pitch, it accommodates virtually all through-hole components, ICs, headers, and modules. Its generous 10×22 cm size provides ample space for medium to large projects, while the 1.2mm fiberglass base ensures durability and reliability. Perfect for prototyping, soldering practice, and permanent DIY electronic builds.
لوحة PCB نموذجية أحادية الوجه قياس 10×22 سم هي لوحة دوائر مثقبة عالمية عالية الجودة، مصممة لبناء واختبار الدوائر الإلكترونية دون الحاجة إلى تصنيع PCB مخصص. تحتوي على 2,730 ثقباً معدنياً بمسافة قياسية 2.54 مم، وتتسع لجميع المكونات ذات الأطراف السلكية والدوائر المتكاملة وموصلات الهيدر. مقاسها الواسع 10×22 سم يوفر مساحة كافية للمشاريع المتوسطة والكبيرة، بينما تضمن قاعدة الفايبر جلاس بسماكة 1.2 مم المتانة والموثوقية. مثالية لـ النماذج الأولية، والتدريب على اللحام، والمشاريع الإلكترونية الدائمة.
The Single-Sided Prototype PCB (10 × 22 cm) is a universal perforated circuit board that provides a reliable foundation for building, testing, and finalizing electronic circuits. Unlike a breadboard, which is meant for temporary connections, this prototype board allows you to solder components permanently, creating durable, vibration-resistant builds suitable for finished projects, enclosures, and field deployment.
The board features a single-sided copper layer on a fiberglass (FR-4 or similar) base, with 2,730 pre-drilled and copper-plated holes arranged in a standard 2.54mm × 2.54mm grid. This pitch is the industry standard for through-hole components, DIP ICs, pin headers, terminal blocks, and most modules, making the board universally compatible with the widest range of electronic parts.
With its generous size of 10 × 22 cm, this PCB is ideal for larger or more complex projects that may not fit on smaller prototype boards. You have plenty of room to lay out multiple ICs, sensor modules, power regulators, and connectors, making it a great choice for full-system designs, custom shields, control panels, and homemade instruments.
The 1.2mm thick board offers excellent mechanical strength and rigidity, while the copper traces accept solder cleanly and hold components securely. Each hole is reinforced with a copper pad, ensuring strong electrical and mechanical bonds during soldering.
Whether you're a student learning to solder, a hobbyist building a finished version of a breadboard prototype, or an engineer testing a new circuit design, this board delivers professional-grade results at a fraction of the cost of custom-fabricated PCBs.
Specifications
- Product Type: Universal Prototype Perforated PCB
- Material: Single-Sided Copper PCB on fiberglass base
- Board Size: 10 cm × 22 cm
- Board Thickness: 1.2 mm
- Hole Diameter: 1 mm
- Hole Pitch (Spacing): 2.54 mm × 2.54 mm (0.1 inch standard)
- Total Hole Count: 2,730 holes
- Copper Layer: Single-sided (one layer of copper pads)
- Solderability: Excellent — clean copper pads accept standard solder
- Color: Typical green solder mask (may vary)
- Compatibility: All standard through-hole components, DIP ICs, headers, terminal blocks, and modules
Applications
- Permanent versions of breadboard prototypes for finished electronic projects
- Arduino, ESP32, and Raspberry Pi shields and custom add-on boards
- DIY electronic instruments such as power supplies, signal generators, and meters
- Home automation control boards integrating relays, sensors, and microcontrollers
- Robotics control circuits combining motor drivers, sensors, and logic
- Audio amplifier and effects pedal builds for hobbyists and musicians
- LED display panels and lighting controllers
- Power distribution boards with regulators, fuses, and terminals
- Sensor interface boards for environmental, motion, or industrial sensing
- Educational electronics labs for soldering practice and circuit assembly
- STEM and university projects requiring durable circuit builds
- Custom mounting boards for enclosure-based electronics
- Repair and replacement boards for damaged commercial electronics
- IoT prototype builds combining microcontrollers, modules, and connectors
