SINGLE SIDED GREEN PCB 9x10 CM

5.0(1 review)
SKU: ME-5789
JD1.75

The Single-Sided Green PCB Prototype Board 9 × 10 cm is a versatile prototyping board designed for building and testing electronic circuits quickly and efficiently. Manufactured from durable FR4 fiberglass material, it features a single copper layer with a standard 2.54 mm hole pitch, making it compatible with most through-hole electronic components. The green solder mask helps prevent accidental short circuits and improves circuit visibility during assembly. Its 9 × 10 cm size provides ample working area for hobbyists, students, engineers, and DIY enthusiasts developing custom electronic projects and prototype designs.

تُعد لوحة الدوائر المطبوعة الخضراء أحادية الوجه 9 × 10 سم خيارًا مثاليًا لتجميع واختبار النماذج الأولية للدوائر الإلكترونية بسهولة وكفاءة. تم تصنيعها من مادة الألياف الزجاجية FR4 المتينة، وتحتوي على طبقة نحاسية واحدة مع تباعد ثقوب قياسي يبلغ 2.54 مم، مما يجعلها متوافقة مع معظم المكونات الإلكترونية ذات الأطراف التقليدية. يساعد قناع اللحام الأخضر على تقليل احتمالية حدوث دوائر قصر وتحسين وضوح مسارات التوصيل أثناء التركيب. يوفر حجمها 9 × 10 سم مساحة عمل مناسبة للمشاريع التعليمية والهوايات والتطبيقات الإلكترونية المختلفة.

Breadboard & PCB

The Single-Sided Green PCB Prototype Board 9 × 10 cm is a practical solution for assembling, testing, and modifying electronic circuits without the need for custom PCB manufacturing. It is designed with a single copper-clad layer and a matrix of pre-drilled holes arranged on a standard 2.54 mm (0.1 inch) pitch, ensuring compatibility with a wide range of through-hole components such as resistors, capacitors, IC sockets, connectors, LEDs, and transistors.

Constructed from durable FR4 fiberglass, the board offers excellent mechanical strength, heat resistance, and electrical insulation properties. The green solder mask protects the copper surface against oxidation while minimizing the risk of accidental solder bridges and short circuits.

Its 9 × 10 cm dimensions provide sufficient space for medium-sized electronic projects, making it suitable for educational use, product development, prototyping, repairs, and DIY electronics applications. The board can be easily cut or modified to meet specific project requirements.

Specifications

ParameterValue
Product TypePrototype PCB Board
Board TypeSingle-Sided
Board ColorGreen
MaterialFR4 Fiberglass
Copper Layers1 Layer
Hole Pitch2.54 mm (0.1 inch)
Hole TypePre-drilled Through Holes
Board Dimensions90 × 100 mm
Compatible ComponentsThrough-hole components
Solder MaskGreen
ApplicationCircuit prototyping and testing

Applications

  • Electronic circuit prototyping
  • Educational and laboratory projects
  • DIY electronics development
  • Microcontroller and Arduino projects
  • Sensor interface circuits
  • Power supply prototypes
  • Robotics applications
  • Repair and modification of electronic devices
  • Testing custom circuit designs
  • Small-scale production projects
