SINGLE SIDE PROTOTYPE PCB 7x9 CM
Single Side Prototype PCB 7×9 cm is a versatile universal prototyping board designed for building, testing, and developing electronic circuits. Featuring a single-sided copper layer, this PCB allows easy soldering and circuit assembly for hobbyists, students, and professional engineers. With a standard 2.54mm hole spacing, it is compatible with most through-hole electronic components, including resistors, capacitors, IC sockets, and connectors. The board measures 7cm × 9cm, providing ample space for circuit development and experimentation. Its durable bakelite construction and pre-drilled holes make it an ideal solution for rapid prototyping, educational projects, and electronic product development.
لوحة دوائر مطبوعة تجريبية أحادية الوجه 7×9 سم هي لوحة متعددة الاستخدامات مصممة لبناء واختبار وتطوير الدوائر الإلكترونية بسهولة. تحتوي على طبقة نحاسية أحادية الوجه تسمح بتركيب ولحام المكونات الإلكترونية بطريقة عملية وسريعة. بفضل المسافة القياسية بين الثقوب 2.54 مم، فهي متوافقة مع معظم المكونات الإلكترونية ذات الأطراف التقليدية مثل المقاومات والمكثفات وقواعد الدوائر المتكاملة والموصلات. توفر مساحة عمل بقياس 7 سم × 9 سم مناسبة لمختلف المشاريع التعليمية والهندسية. كما تتميز بمتانتها وسهولة استخدامها في النمذجة الأولية، والتجارب الإلكترونية، ومشاريع التطوير والابتكار.
The Single Side Prototype PCB 7×9 cm is a universal experimental circuit board designed for rapid electronic prototyping and circuit development. It features a single-sided copper-clad layout that allows users to create custom electronic circuits without the need for manufacturing a dedicated PCB.
The board is constructed from durable bakelite material and includes a grid of pre-drilled holes with a standard 2.54mm pitch, making it compatible with most through-hole electronic components and development modules. The 1.0mm hole diameter accommodates common component leads, headers, and connectors.
Its 7cm × 9cm size provides sufficient space for building medium-sized electronic projects while remaining compact enough for integration into enclosures and prototype systems. The board is widely used in educational environments, electronics laboratories, hobby projects, Arduino-based systems, robotics, and product development.
This prototype PCB offers a cost-effective and convenient solution for testing circuit designs, assembling custom electronic devices, and creating permanent prototypes before final PCB production.
Specifications
| Parameter | Specification |
|---|---|
| Product Name | Single Side Prototype PCB |
| Board Type | Universal Prototype PCB |
| Board Size | 7 cm × 9 cm |
| PCB Type | Single-Sided Copper Board |
| Material | Bakelite |
| Board Color | Yellow |
| Thickness | 1.2 mm |
| Hole Spacing (Pitch) | 2.54 mm |
| Hole Diameter (Aperture) | 1.0 mm |
| Mounting Style | Through-Hole Components |
| Copper Layer | Single Side |
| Application | Circuit Prototyping and Development |
Applications
- Electronic circuit prototyping
- Arduino and microcontroller projects
- Educational electronics training
- Robotics development
- Sensor interface circuits
- DIY electronic projects
- Product development and testing
- Analog and digital circuit experiments
- Laboratory and research projects
- Permanent prototype construction
