IR DISTANCE SENSING MODULE 45CM
The IR Distance Sensing Module (5–45 cm) detects solid objects using infrared reflection and provides a digital output for easy interfacing. Its range is adjustable via the on-board potentiometer, making it ideal for robots, automation, and object-avoidance systems. Operating on 3–6V, it delivers reliable detection with a 35° sensing angle and TTL-level output.
وحدة استشعار المسافة بالأشعة تحت الحمراء (5–45 سم) تكشف الأجسام الصلبة عبر الانعكاس، وتوفر خرجًا رقميًا يسهل ربطه بالأنظمة المختلفة. يمكن ضبط المدى باستخدام مقاومة الضبط على اللوحة، مما يجعلها مثالية للروبوتات وتجنب العوائق. تعمل بجهد 3–6 فولت وتوفر كشفًا موثوقًا بزاوية استشعار 35° وإشارة خرج TTL.
The IR Distance Sensing Module is designed to detect solid objects using infrared reflection technology and provides a simple digital output for microcontrollers, robots, and automation systems. It features an adjustable detection range of approximately 5 to 45 cm, controlled by an on-board potentiometer, allowing it to adapt to various environmental and surface conditions.
This compact and efficient module operates with a supply voltage of 3–6V and consumes only 20 mA. With a 35° effective sensing angle and TTL-level output, it is suitable for obstacle detection, proximity sensing, and object-avoidance applications. Its 4-pin interface (-/+/S/EN) ensures easy integration with Arduino, Raspberry Pi, and other control boards.
The module outputs 0 when an object is detected and 1 when no object is present, providing straightforward logic for automation and robotic systems.
Specifications
Supply Voltage: 3–6V
Working Current: 20 mA
Working Temperature: –10°C to +50°C
Sensing Range: 5–45 cm (adjustable)
Output Signal: TTL Digital
Effective Angle: 35°
Interface: 4-pin (- / + / S / EN)
Module Size: 4.5 × 1.1 cm (approx.)
Digital Output:
0 = object detected
1 = no object detected
