8×8 RGB LED Dot Matrix

Description:

This 5 mm 8x8 RGB LED Dot Matrix is very useful for development projects which need LED display of number, letters, or figures.

CILE 2088RGB-5

Do you know how is the cool advertising display made? It is exactly composed of these small RGB LED matrix. If you want to make a similar display, this RGB LED matrix will meet you need. The 8×8 LED matrix has 32 of pins, you may need a driver to control it.



  • Full color RGB variation

  • Circular LED point source





Specifications (IF = 20mA)

  • Forward voltage(RED): DC 2.2V

  • Forward voltage(GREEN): DC 3.3V

  • Forward voltage(BLUE): DC 3.3V

  • Luminous intensity(RED): 140mcd

  • Luminous intensity(GREEN): 280mcd

  • Luminous intensity(BLUE): 80mcd

  • Wavelength(RED): 620~622.5nm

  • Wavelength(GREEN): 520~522.5nm

  • Wavelength(BLUE): 465~467.5nm



This 5 mm LED dot matrix is composed of 64 elements arranged in 8 x 8 matrix that is very useful for development projects which need LED display of number, letters, or figures.

In order to function properly, each LED needs some voltage drop and current as follows: red LED needs 1.8V - 2.2V and a maximum of 20mA (recommended 15 - 18mA), the green LED needs 2V - 2.4V and a maximum 20mA (recommended 15 - 18mA) and blue LED needs 3V - 3.4V and a maximum of 20mA (recommended 15 - 18mA).

The size of the matrix x 60.5 mm to 60.5. For more details on connections matrix or other dimensions, see the attached picture.

 With this module and an Arduino-compatible development board, you can create your own Snake game.

Specifications

  • LED diameter: 5 mm
  • Voltage drop: 1.8 V to  2.2 V (red), 2 V to  2..4 V (green), 3 V to 3.4 V (blue)
  • LED current: 20 mA (max)
  • Dimensions: 60.5 mm x 60.5 mm




Kit include:

1 x 8×8 RGB LED Dot Matrix

10 JD
Quantity
In stock
