Note:

without case

Features:

• Maximum Real-time Sampling Rate: 1Msps

• Accuracy: 12Bit
• Sampling Buffer Depth: 1024 bytes
• Analog Bandwidth: 0-200KHz
• Vertical Sensitivity: 10mV / Div - 5V / Div (1-2-5 progressive manner)
• Input Impedance: 1MΩ
• Maximum Input Voltage: 50Vpp (1: 1 probe), 400Vpp (10: 1 probe)
• Coupling Modes: DC / AC / GND
• The Horizontal Time Base Range: 10μs / Div - 50s / Div (1-2-5 progressive manner)
• Supply Voltage: DC 9V
